Lightbox exhibition stand 6m x 6m with a counter and optional TV mount
In Stock
Delivery in 7-10 working daysfrom £8,388.00 (exc. VAT)
Lightbox exhibition stand 6m x 6m with a counter and optional TV mount
In Stock
Delivery in 7-10 working daysfrom £8,388.00 (exc. VAT)
The lightbox exhibition stand system consists of our portable lightbox display walls connected together using connector fixings. The edgelit fabric graphic has a specialist and patented silicone design, meaning that you get minimal shadowing where the graphic meets the frame. This enables you to connect lightboxes to each other with beautifully discreet joins. The individual lightboxes are easy to build with feet, ideal for the exhibition and events circuit and popular in the retail and leisure sectors.
Not sure if this is the right product for you?
Ask about this productThe lightbox exhibition stand system consists of our portable lightbox display walls connected together using connector fixings. The edgelit fabric graphic has a specialist and patented silicon design, meaning that you get minimal shadowing where the graphic meets the frame. This enables you to connect lightboxes to each other with beautifully discreet joins. The individual lightboxes are easy to build with feet, ideal for the exhibition and events circuit and popular in the retail and leisure sectors.
Our portable lightbox display walls are made using 80mm deep aluminium profiles with edgelit LEDs, meaning they can be used as a single sided or double sided lightbox display. If you opt for the single sided lightbox you will receive a custom printed fabric graphic for the front of your lightbox and a non printed block out fabric for the back. if you opt for the double sided lightbox you will receive a custom printed fabric graphic for both the front and back of the lightbox.
Additional custom printed fabric graphics can be purchased in the future as and when you need to change your marketing message. You can see the replacement graphic options here. Equally, additional block out fabrics can be purchased if you want to alternate between a double sided and single sided lightbox display. The fabric graphics are produced on stretch display polyester and finished with a silicon beading, which slots into the framework giving you a flush finish with a clean, almost frameless appearance.
Important: you must satisfy yourself that this configuration is suitable for your overall floor space. The individual lightbox dimensions should be checked in the dimensions and specification tab above, rather than just relying on the overall size given in the title for this product listing, which is an approximate overall size. The use of feet and the order in which you connect the lightboxes at a right angle can alter the overall size.
This kit includes as standard
- Five 2953mm wide x 2400mm high lightbox (also referred to as 3m wide portable lightbox on our website)
- One 1373mm wide x 2400mm high lightbox (also referred to as 1.4m wide portable lightbox on our website)
- 1000mm wide x 1050mm high x 500mm depth lightbox counter (also referred to as 1m SEG lightbox counter on our website)
- Six large wheeled cases
- One soft moulded cases
- Lightbox wall graphics for single sided option (six printed graphics and six plain block out rear fabrics) or graphics for double sided option (twelve printed graphics). If you would like to order a combination of single and double sided graphics please call our friendly team who will quote for the exact combination of prints/rear plain block-out fabrics that you require.
- Lightbox counter graphics to cover front, back and both sides
- Two right angle connector packs, two straight line connector packs and one 90° triple connector. Additional connector packs can be purchased here in the event that you wanted to use your lightboxes in different layouts.
Optional extras
-
- TV mounts compatible with the 1.4m wide portable lightbox. Comes with a universal VESA bracket and is suitable for TVs weighing up to 5 kg. If selected the lightbox graphic is produced with holes in the front for the TV fixing point. Therefore it is not recommended that you use the same graphic without a TV. If you would like the option of not using a TV with this stand on occasion, you will need to add a second fabric graphic to your order.
- Counter conversion kit for turning the large wheeled case for the 3m lightbox that is included as standard into a counter (counter conversion kit comes with a counter top and printed fabric graphic). For full product details see here.
Need help with your artwork? We supply graphic design services from as little as £25 (price stated is for supplied logo placement on a plain background). Contact us for a quotation on 01733 570222.
Feet | 2 aluminium feet per lightbox |
Hardware | Aluminium |
Graphic | Backlit display polyester |
Bag | Supplied in a padded carry bag (1373mm lightbox) and a large wheeled case (2953mm wide lightbox) |
Warranty | Hardware comes with a 1 year guarantee |
Assembly | Tool free assembly |
Connectors | 2 x right angle, 2 x straight line connectors and 1 x 90° triple |
Height (mm) |
Width (mm) |
Depth (mm) |
|
---|---|---|---|
Lightbox 1 | 2400mm | 2953mm | 80mm |
Lightbox 2 | 2400mm | 2953mm | 80mm |
Lightbox 3 | 2400mm | 2953mm | 80mm |
Lightbox 4 | 2400mm | 2953mm | 80mm |
Lightbox 5 | 2400mm | 2953mm | 80mm |
Lightbox 6 | 2400mm | 1373mm | 80mm |
Counter | 1050mm | 1000mm | 500mm |
Feet | 6mm | 50mm | 480mm |
Large wheeled case | 320mm (as a case) / 1000mm (as a counter) | 1000mm (as a case) / 1000mm (as a counter) | 500mm (as a case) / 500mm (as a counter) |
